Dell 0RKNY System Board (Motherboard) For Poweredge Server

This enterprise-grade server motherboard is designed to meet the performance and scalability demands of modern data centers, virtualization hosts, and high-compute environments. With support for dual Intel® Xeon® Scalable processors and up to 4TB of memory, it combines robust hardware with enterprise-class features including hardware RAID, management interfaces, and extensive I/O. Ideal for servers, HPC, storage systems, and more.

Quote Now

CPU & Bus

Socket: 2 x LGA 3647 (Socket P, square type)
Supported CPUs: Intel® Xeon® Scalable (1st & 2nd Gen)
System Bus: UPI up to 10.4 GT/s
Check ASUS CPU support list for details.

Chipset

Core Logic: Intel® Lewisburg C621

Memory

DIMM Slots: 8 (4 per CPU)
Capacity:
- Up to 256GB RDIMM
- Up to 512GB LRDIMM
- Up to 4TB LRDIMM 3DS
Frequencies: 2933 / 2666 / 2400 MHz
Types: RDIMM, LRDIMM, LRDIMM 3DS
Frequency may vary by CPU. Refer to Intel specs.

Expansion

Total Slots: 3
PCIe Slots:
- 1 x PCI-E x8
- 2 x PCI-E x16

Form Factor

Type: CEB (12″ x 10.5″ / 305mm x 267mm)

ASUS Features

ASUS Fan Speed Control
ASUS Control Center (Remote Mgmt)

Storage

SATA: 8 × SATA 6Gb/s (via 2 Mini-SAS)
M.2: 1 x M.2 (via Mini-SAS HD)
RAID: Intel® RSTe (RAID 0,1,5,10)
SAS (via Add-on):
- ASUS PIKE II 3008-8i (12G RAID)
- ASUS PIKE II 3108-8i (12G HW RAID)

Networking

2 × Intel® I210AT Gigabit LAN
1 × Dedicated IPMI Mgmt LAN

Graphics

ASPEED AST2500 with 64MB VRAM (Integrated)
